Specifications: (unit: mm)
| Model | Bearing Type |
Rated Voltage |
Operation Voltage |
Current | Speed | Air Flow |
Static Pressure |
Noise Level |
Weight |
| VDC | VDC | A | RPM | CFM | mmH20 | dBA | g | ||
| ZDH9025S | Sleeve | 12 | 10.8～13.2 | 0.25 | 2800 | 54.73 | 3.04 | 32.81 | 85 |
| ZDM9025S | 0.20 | 2500 | 46.46 | 2.11 | 28.58 | ||||
| ZDL9025S | 0.16 | 2000 | 39.87 | 1.67 | 25.87 | ||||
| ZDH9025B | Ball | 0.25 | 2800 | 54.73 | 3.04 | 32.81 | |||
| ZDM9025B | 0.20 | 2500 | 46.46 | 2.11 | 28.58 | ||||
| ZDL9025B | 0.16 | 2000 | 39.87 | 1.67 | 25.87 | ||||
| ZDH9025S | Sleeve | 24 | 21.6～26.4 | 0.15 | 2800 | 54.73 | 3.04 | 32.81 | |
| ZDM9025S | 0.10 | 2500 | 46.46 | 2.11 | 28.58 | ||||
| ZDL9025S | 0.07 | 2000 | 39.87 | 1.67 | 25.87 | ||||
| ZDH9025B | Ball | 0.15 | 2800 | 54.73 | 3.04 | 32.81 | |||
| ZDM9025B | 0.10 | 2500 | 46.46 | 2.11 | 28.58 | ||||
| ZDL9025B | 0.07 | 2000 | 39.87 | 1.67 | 25.87 |
● Dimensions Drawing
● Characteristic Curves
