80X80X25

DC Axial-Flow Fan Motor

Material: Frame And Impeller:Thermal Plastic UL 94-0

Lead Wires:UL Type

RED Wire Positive(+)

Black Wire Negative(-)

Insulation Resistance: 10MΩ Or Over With a DC250V Megger

Dielectric Withstand Voltage: AC500V 1S

Allowable Ambient Temperature Range: -10℃～+70℃(Operating) -40℃～+70℃(Storage)

Description
Reviews (0)

Specifications: (unit: mm)

Model	Bearing Type	Rated Voltage	Operation Voltage	Current	Speed	Air Flow	Static Pressure	Noise Level	Weight
Model	Bearing Type	VDC	VDC	A	RPM	CFM	mmH₂0	dBA	g
ZDH8025S	Sleeve	12	10.8～13.2	0.17	3000	38.88	3.54	32.31	73
ZDM8025S				0.11	2500	32.37	2.52	27.85
ZDL8025S				0.08	2000	25.64	1.64	22.05
ZDH8025B	Ball			0.17	3000	38.88	3.54	32.31
ZDM8025B				0.11	2500	32.37	2.52	27.85
ZDL8025B				0.08	2000	25.64	1.64	22.05
ZDH8025S	Sleeve	24	21.6～26.4	0.15	3000	38.88	3.54	32.31
ZDM8025S				0.10	2500	32.37	2.52	27.85
ZDL8025S				0.07	2000	25.64	1.64	22.05
ZDH8025B	Ball			0.15	3000	38.88	3.54	32.31
ZDM8025B				0.10	2500	32.37	2.52	27.85
ZDL8025B				0.07	2000	25.64	1.64	22.05

● Dimensions Drawing

● Characteristic Curves
