Specifications: (unit: mm)
| Model | Bearing Type |
Rated Voltage |
Operation Voltage |
Current | Speed | Air Flow |
Static Pressure |
Noise Level |
Weight |
| VDC | VDC | A | RPM | CFM | mmH20 | dBA | g | ||
| ZDH8010S | Sleeve | 5 | 4.5～5.5 | 0.35 | 3000 | 23.45 | 1.81 | 30.75 | 43 |
| ZDM8010S | 0.25 | 2500 | 19.68 | 1.31 | 26.25 | ||||
| ZDL8010S | 0.17 | 2000 | 15.58 | 0.90 | 22.08 | ||||
| ZDH8010B | Ball | 0.35 | 3000 | 23.45 | 1.81 | 30.75 | |||
| ZDM8010B | 0.25 | 2500 | 19.68 | 1.31 | 26.25 | ||||
| ZDL8010B | 0.17 | 2000 | 15.58 | 0.90 | 22.08 | ||||
| ZDH8010S | Sleeve | 12 | 10.8～13.2 | 0.24 | 3000 | 23.45 | 1.81 | 30.75 | |
| ZDM8010S | 0.18 | 2500 | 19.68 | 1.31 | 26.25 | ||||
| ZDL8010S | 0.12 | 2000 | 15.58 | 0.90 | 22.08 | ||||
| ZDH8010B | Ball | 0.24 | 3000 | 23.45 | 1.81 | 30.75 | |||
| ZDM8010B | 0.18 | 2500 | 19.68 | 1.31 | 26.25 | ||||
| ZDL8010B | 0.12 | 2000 | 15.58 | 0.90 | 22.08 |
● Dimensions Drawing
● Characteristic Curves
