DC Axial-Flow Fan Motor
Material: Frame And Impeller:Thermal Plastic UL 94-0
Lead Wires:UL Type
RED Wire Positive(+)
Black Wire Negative(-)
Insulation Resistance: 10MΩ Or Over With a DC250V Megger
Dielectric Withstand Voltage: AC500V 1S
Allowable Ambient Temperature Range:-10℃～+70℃(Operating) -40℃～+70℃(Storage)
Specifications:(unit: mm)
| Model | Bearing Type |
Rated Voltage |
Operation Voltage |
Current | Speed | Air Flow |
Static Pressure |
Noise Level |
Weight |
| VDC | VDC | A | RPM | CFM | mmH20 | dBA | g | ||
| ZBM6015S | Sleeve | 5 | 4.5～5.5 | 0.35 | 3500 | 3.60 | 10.02 | 33.5 | 35 |
| ZBL6015S | 0.12 | 2800 | 3.00 | 7.92 | 28.2 | ||||
| ZBM6015S | Sleeve | 12 | 10.8～13.2 | 0.20 | 3500 | 3.60 | 10.02 | 33.5 | |
| ZBL6015S | 0.16 | 2800 | 3.00 | 7.92 | 28.2 |
● Dimensions Drawing
● Characteristic Curves
