6010

60102

60X60X10

DC Axial-Flow Fan Motor

Material: Frame And Impeller:Thermal Plastic UL 94-0

Lead Wires:UL Type

RED Wire Positive(+)

Black Wire Negative(-)

Insulation Resistance: 10MΩ Or Over With a DC250V Megger

Dielectric Withstand Voltage: AC500V 1S

Allowable Ambient Temperature Range: -10℃～+70℃(Operating) -40℃～+70℃(Storage)

Description
Reviews (0)

Specifications: (unit: mm)

Model	Bearing Type	Rated Voltage	Operation Voltage	Current	Speed	Air Flow	Static Pressure	Noise Level	Weight
Model	Bearing Type	VDC	VDC	A	RPM	CFM	mmH₂0	dBA	g
ZDH6010S	Sleeve	5	4.5～5.5	0.35	4000	17.17	3.15	28.86	27
ZDM6010S				0.30	3500	14.78	2.38	26.38
ZDL6010S				0.25	3000	12.30	1.67	23.33
ZDH6010B	Ball			0.35	4000	17.17	3.15	28.86
ZDM6010B				0.30	3500	14.78	2.38	26.38
ZDL6010B				0.25	3000	12.30	1.67	23.33
ZDH6010S	Sleeve	12	10.8～13.2	0.23	4000	17.17	3.15	28.86
ZDM6010S				0.17	3500	14.78	2.38	26.38
ZDL6010S				0.13	3000	12.30	1.67	23.33
ZDH6010B	Ball			0.23	4000	17.17	3.15	28.86
ZDM6010B				0.17	3500	14.78	2.38	26.38
ZDL6010B				0.13	3000	12.30	1.67	23.33

● Dimensions Drawing

● Characteristic Curves
