50X50X15

50X50X15 - Image 2

50X50X15 - Image 3

50X50X15

DC Axial-Flow Fan Motor

Material: Frame And Impeller:Thermal Plastic UL 94-0

Lead Wires:UL Type

RED Wire Positive(+)

Black Wire Negative(-)

Insulation Resistance: 10MΩ Or Over With a DC250V Megger

Dielectric Withstand Voltage: AC500V 1S

Allowable Ambient Temperature Range: -10℃～+70℃(Operating) -40℃～+70℃(Storage)

Description
Reviews (0)

Specifications: (unit: mm)

Model	Bearing Type	Rated Voltage	Operation Voltage	Current	Speed	Air Flow	Static Pressure	Noise Level	Weight
Model	Bearing Type	VDC	VDC	A	RPM	CFM	mmH₂0	dBA	g
ZDH5015S	Sleeve	5	4.5～5.5	0.30	5500	16.50	4.58	36.42	29
ZDM5015S				0.23	4500	13.94	3.04	31.74
ZDL5015S				0.17	3500	10.85	2.25	29.39
ZDH5015B	Ball			0.30	5500	16.50	4.58	36.42
ZDM5015B				0.23	4500	13.94	3.04	31.74
ZDL5015B				0.17	3500	10.85	2.25	29.39
ZDH5015S	Sleeve	12	10.8～13.2	0.16	5500	16.50	4.58	36.42
ZDM5015S				0.12	4500	13.94	3.04	31.74
ZDL5015S				0.08	3500	10.85	2.25	29.39
ZDH5015B	Ball			0.16	5500	16.50	4.58	36.42
ZDM5015B				0.12	4500	13.94	3.04	31.74
ZDL5015B				0.08	3500	10.85	2.25	29.39

● Dimensions Drawing

● Characteristic Curves
