DC Axial-Flow Fan Motor
Material: Frame And Impeller:Thermal Plastic UL 94-0
Lead Wires:UL Type
RED Wire Positive(+)
Black Wire Negative(-)
Insulation Resistance: 10MΩ Or Over With a DC250V Megger
Dielectric Withstand Voltage: AC500V 1S
Allowable Ambient Temperature Range: -10℃～+70℃(Operating) -40℃～+70℃(Storage)
|
Model |
Bearing |
Rated Voltage |
Operation Voltage |
Current | Speed | Air Flow |
Static Pressure |
Noise Level |
Weight |
| VDC | VDC | A | RPM | CFM | mmH20 | dBA | g | ||
| ZDH2507S | Sleeve | 5 | 4.5～5.5 | 0.20 | 10000 | 1.92 | 3.55 | 22.50 | 6 |
| ZDM2507S | 0.16 | 9000 | 1.80 | 2.64 | 20.58 | ||||
| ZDL2507S | 0.12 | 8000 | 1.60 | 1.58 | 20.18 | ||||
| ZDH2507S | 12 | 10.8～13.2 | 0.15 | 10000 | 1.92 | 3.55 | 22.50 | ||
| ZDM2507S | 0.12 | 9000 | 1.80 | 2.64 | 20.58 | ||||
| ZDL2507S | 0.09 | 8000 | 1.60 | 1.58 | 20.18 |
● Dimensions Drawing
● Characteristic Curves
