DC Axial-Flow Fan Motor
Material: Frame And Impeller:Thermal Plastic UL 94-0
Lead Wires:UL Type
RED Wire Positive(+)
Black Wire Negative(-)
Insulation Resistance: 10MΩ Or Over With a DC250V Megger
Dielectric Withstand Voltage: AC500V 1S
Allowable Ambient Temperature Range: -10℃～+70℃(Operating) -40℃～+70℃(Storage)
Specifications: (unit: mm)
| Model | Bearing Type |
Rated Voltage |
Operation Voltage |
Current | Speed | Air Flow |
Static Pressure |
Noise Level |
Weight |
| VDC | VDC | A | RPM | CFM | mmH20 | dBA | g | ||
| ZDH4007S | Sleeve | 5 | 4.5-5.5 | 0.26 | 7000 | 6.07 | 3.03 | 31.59 | 8.5 |
| ZDM4007S | 0.20 | 6000 | 5.20 | 2.60 | 27.08 | ||||
| ZDL4007S | 0.12 | 5000 | 4.34 | 2.17 | 22.57 | ||||
| ZDH4007S | 12 | 10.8-13.2 | 0.13 | 7000 | 6.07 | 3.03 | 31.59 | ||
| ZDM4007S | 0.10 | 6000 | 5.20 | 2.60 | 27.08 | ||||
| ZDL4007S | 0.07 | 5000 | 4.34 | 2.17 | 22.57 |
● Dimensions Drawing
● Characteristic Curves
