120X120X32-Blower

DC Axial-Flow Fan Motor

Material: Frame And Impeller:Thermal Plastic UL 94-0

Lead Wires:UL Type

RED Wire Positive（+）

Black Wire Negative(-)

Insulation Resistance: 10MΩ Or Over With a DC250V Megger

Dielectric Withstand Voltage: AC500V 1S

Allowable Ambient Temperature Range:-10℃～+70℃(Operating) -40℃～+70℃(Storage)

Description
Reviews (0)

Specifications: (unit: mm)

Model	Bearing Type	Rated Voltage	Operation Voltage	Current	Speed	Air Flow	Static Pressure	Noise Level	Weight
Model	Bearing Type	VDC	VDC	A	RPM	CFM	mmH₂0	dBA	g
ZBH1232S	Sleeve	12	10.8～13.2	0.60	2100	31.83	25.10	45.8	240
ZBM1232S				0.50	1800	28.89	18.55	43.7
ZBL1232S				0.32	1600	25.87	14.10	40.9
ZBH1232B	Ball			0.60	2100	31.83	25.10	45.8
ZBM1232B				0.50	1800	28.89	18.55	43.7
ZBL1232B				0.32	1600	25.87	14.10	40.9
ZBH1232S	Sleeve	24	21.6～26.4	0.40	2100	31.83	25.10	45.8
ZBM1232S				0.30	1800	28.89	18.55	43.7
ZBL1232S				0.20	1600	25.87	14.10	40.9
ZBH1232B	Ball			0.40	2100	31.83	25.10	45.8
ZBM1232B				0.30	1800	28.89	18.55	43.7
ZBL1232B				0.20	1600	25.87	14.10	40.9

● Dimensions Drawing

● Characteristic Curves
