120X120X25-AC

AC Axial-Flow Fan Motor
● General Specifications
○ Material:
Impeller: PBT UL 94V-0 Reinforced Plastic
Frame :Aluminium Alloy
○ Lead Wires: UL Type
○ Motor Protection:ImpeSAnce Protect
○ Insulation Resistance:10MΩ Or Over With a DC500V Megger
○ Dielectric Withstand Voltage:AC1500V 3S
○ Allowable Ambient Temperature Range:
-10℃～+70℃(Operating)
-40℃～+70℃(Storage)

Description
Reviews (0)

Specifications:(unit: mm)

Model	Bearing Type	Rated Voltage	Fre- quency	Current	Power	Speed	Noise Level	Air Flow		Static Pressure	Weight
Model	Bearing Type	VDC	Hz	A	W	RPM	dBA	M³/hr	CFM	mmH₂0	g
ZAH1225S	Sleeve	220-240	50/60	0.07	14/13	2150/2450	34/39	100/115	59/68	4.0/4.3	370
ZAM1225S		220-240	50/60	0.06	11/10	2000/2200	33/34	94/102	55/60	3.0/3.7
ZAL1225S		220-240	50/60	0.05	9/8	1800/1800	31/31	85/85	50/50	2.2/2.2
ZAH1225S		100-125	50/60	0.17	14/13	2150/2450	34/39	100/115	59/68	4.0/4.3
ZAM1225S		100-125	50/60	0.13	11/10	2000/2200	33/34	94/102	55/60	3.0/3.7
ZAL1225S		100-125	50/60	0.09	9/8	1800/1800	31/31	85/85	50/50	2.2/2.2
ZAH1225S	Ball	220-240	50/60	0.07	14/13	2150/2450	34/39	100/115	59/68	4.0/4.3
ZAM1225S		220-240	50/60	0.06	11/10	2000/2200	33/34	94/102	55/60	3.0/3.7
ZAL1225S		220-240	50/60	0.05	9/8	1800/1800	31/31	85/85	50/50	2.2/2.2
ZAH1225S		100-125	50/60	0.17	14/13	2150/2450	34/39	100/115	59/68	4.0/4.3
ZAM1225S		100-125	50/60	0.13	11/10	2000/2200	33/34	94/102	55/60	3.0/3.7
ZAL1225S		100-125	50/60	0.09	9/8	1800/1800	31/31	85/85	50/50	2.2/2.2

● Dimensions Drawing

● Characteristic Curves
